Aerox AX066 MP1 1/10 Scale High-Speed Brushless Servo for RC Cars - Perfect for Racing, Crawling, and Off-Road RC Vehicles

Product Description

Introducing the new AEROX MP1 1/10th Brushless Servo.

This servo is for high level competition, boasting a full metal case, brushless motor, titanium and steel gears and is perfectly specified for speed and torque requirements for 1/10th Off Road Buggies.

Tested and approved by Schumacher engineers and team drivers to perform at the highest level!

Primarily designed as a mid size servo for 1/10th Off Road Cars, however the AEROX MP1 can be used in many vehicle types.

The MP1 has a 4 pole brushless motor giving higher performance, longer life, greater heat resistance and faster response.

Specifications

• Torque(6.0V): 20.0 kg-cm / (277.7 oz/in)

• Torque(7.4V): 26.0 kg-cm / (361.1 oz/in)

• Torque(8.4V): 30.0 kg-cm / (416.6 oz/in)

• Speed: 0.083 sec (6.0V)

• Speed: 0.067 sec (7.4V)

• Speed: 0.055 sec (8.4V)

• 25T Spline

• Operating Voltage: 6.0 ~ 8.4 DC Volts

• Weight: 63 g (2.22 oz)

• Bearing Type: Ball Bearing x 2

• Motor Type: Brushless Motor

• 25T Spline

• Gear Type: 7075+Steel

• Operating Temperature: -20℃~60℃

• Working frequency: 1520μs / 1666hz

• Size: 41.0 x 20.0 x 29.0 mm

Supports the following radio modes;

• SANWA : NOR / SHR / SSR / SUR / SXR

• Futaba : NOR / SR / UR

• Flysky Noble NB4 : NOR / SR / SFR
